MX 3.5 Female Socket PCB Mounting 5 Pin MX-2264

The MX 3.5mm Female Socket PCB Mounting 5 Pin MX-2264 is a compact and reliable 5-pin 3.5mm EP female socket designed for direct PCB mounting. It provides a convenient interface for compatible audio and signal applications and is suitable for electronic equipment where a secure, board-mounted 3.5mm connection is required.

Key Features and Specifications

1. 3.5mm 5-Pin EP Socket: The MX-2264 features a 3.5mm female socket with 5 electrical contacts, providing additional signal connections compared with a standard 3-contact stereo socket. The actual contact assignment depends on the equipment and circuit design.
2. PCB Mounting Design: Designed for direct installation on a printed circuit board (PCB), the socket provides a fixed connection point while helping maintain a clean and organized internal layout.
3. Compact Construction: Its compact form factor makes the MX-2264 suitable for electronic devices where available PCB space is limited.
4. Easy Installation: The PCB-mount configuration allows the connector to be integrated into electronic assemblies through standard soldering and board-assembly processes.
5. Durable and Reliable: The connector is designed for regular use and repeated mating with compatible 3.5mm plugs, providing a stable connection for suitable signal applications.
6. Five Electrical Contacts: The 5-pin configuration provides multiple contact points that can be assigned according to the requirements of the application. Always verify the pinout before connecting the socket to a circuit.

Applications

The MX 3.5mm Female Socket PCB Mounting 5 Pin MX-2264 is suitable for applications such as:

• Audio equipment and electronic devices
• Headphone and headset interfaces
• Portable electronic equipment
• Audio input and output circuits
• Custom PCB and DIY electronics projects
• Consumer electronic equipment
• Audio testing and signal-routing applications
• Equipment repair and replacement

Product Specifications

• Model: MX-2264
• Type: 3.5mm Female / EP Socket
• Configuration: 5 Pin
• Mounting: PCB Mount
• Connector Gender: Female
• Application: Compatible audio and signal connections
• Design: Compact PCB-mount construction

Important Compatibility Note

A 5-pin 3.5mm socket does not have a universal pin assignment. The additional contacts may be used differently depending on the equipment or circuit design. Before installation, verify the pin configuration, PCB footprint, mechanical dimensions, and electrical requirements of the intended application.

The MX-2264 offers a practical 5-pin 3.5mm PCB-mount connection for compatible electronic and audio applications. Its compact design, multiple contacts, and board-mount construction make it suitable for equipment assembly, repairs, and custom electronics projects.
